Indicator Light. Flat head. Dot light. J pin terminal
Specification Download
Commodity
12mm indicator light
Series
FT-12Z
Mounting Hole Size
12mm
Model
FT12Z-A2
Switch Rating
Head Shape
Flat head Dot light
Stucture
Operation
Terminal
J pin terminal
Protection Grade
IP65 IK10
Lamp Parameters
Color
R
.
Y
.
G
.
B
.
W
other color . double color
Rated Voltage
2V 3V 5V 6V 12V 24V
36V 48V 110V 220V
Rated Current
15mA
Life
50.000 hours
Parameters
Contact Resistance
≤50mΩ
Insulation Resistance
≥1000MΩ
Dielectric Strength
2000VAC/min
Environment Temperature
-20℃~+55℃
Panel Thickness
1~10mm
Nut Torque
5~14Nm
Operating Pressure
3~5N
Operating Stroke
3.0mm
Mechanical Life
1.000.000 times
Electrical Life
50.000 times
Material
Button
Stainless steel / Zn-Al alloy
Body
Stainless steel / Zn-Al alloy / Brass nickel plated
Contact
Silver
Termial
Brass plating silver
Base
PBT
